What Is the Masimo Compatible LNC Ext-4 SpO2 Extension Cable?

The IPR Medical SA-005RB-12LS is a compatible aftermarket replacement for the Masimo LNC Ext-4 (LNC-4-EXT, 2021) SpO2 extension cable. It is not an OEM product. This 4 ft (1.2 m) reusable cable has a 9-pin D-sub (DB9) connector at each end. It extends Masimo LNCS pulse oximetry sensors to monitors, defibrillators, and infant care systems with a DB9-style Masimo SET SpO2 port. It is designed to match the original LNC Ext-4 cable in fit, form, and function.

Compatible Monitor Models

This cable is compatible with a wide range of Mindray/Datascope monitors that have Masimo SET SpO2: Accutorr V, Accutorr 3, Accutorr 7, Accutorr Plus, DPM4, DPM6, DPM7, EPM4, MEC 12, MPM, Passport 2, Passport 2LT, Passport XG, PM 6800, Spectrum, Trio, T8, V12, V21, and VS 800. It also supports the Zoll E Series, M Series, and R Series defibrillators and the GE Datex-Ohmeda S/5 and Giraffe Infant Warmer. Other supported devices include the GE Critikon Dinamap Pro 1000, the Philips Invivo Escort II, the Comen K12 Pro, and Bitmos SAT 800, 801, 805, 816, and satPuls. Before ordering, confirm that your device has a DB9-style Masimo SET SpO2 port and uses LNCS sensors.

Design and Construction

The cable has a triple-keyed 9-pin D-sub connector on each end, joined by a flexible, shielded 4 ft (1.2 m) cable. One end plugs into the monitor’s Masimo SET SpO2 port and the other accepts the DB9 connector of a Masimo LNCS sensor. This lets a short reusable or single-patient-use sensor reach the patient without strain on the sensor cable or the monitor port. The cable is built for Masimo LNCS sensors and will not accept LNOP, M-LNCS, or RD SET sensors. It is reusable and supplied one per bag.

When to Replace Your LNC Ext-4 Extension Cable

Replace the extension cable if you see intermittent or dropped SpO2 readings, or “sensor off” or “no sensor” alarms with a known-good LNCS sensor attached. Other signs include bent or recessed pins on either DB9 connector, cracked connector shells or broken keying, and a cut, crushed, or kinked jacket. Extension cables take repeated flexing and connector cycling at the bedside, so they often fail before the monitor or sensor does. Biomedical technicians can confirm a fault by connecting a known-good sensor directly to the monitor. If readings return to normal, the extension cable should be retired. Keeping a spare on hand helps prevent downtime on transport monitors, crash carts, and infant warmers.

Cross Reference and Interchange Part Numbers

The IPR Medical SA-005RB-12LS cross-references to the following part numbers:

Masimo LNC Ext-4, LNC-4-EXT, LNC DB9, 2021, and 2285; Zoll 8000-0325; Welch Allyn LNC-4-WA; Comen 040-000313-00; and CAS Medical 01-02-0715.

This DB9 extension cable is different from the compatible Masimo LNC-4 patient cable, IPR Medical SKU SA-008RB-12LS. That cable connects LNCS sensors to devices with a gray Masimo SET patient cable connector. If your device has a red Masimo rainbow SET connector, choose the compatible Red LNC series cables: IPR Medical SKU SA-009RB-12LS, SA-009RB-30LS, or SA-009RB-36LS.

Why Source SpO2 Extension Cables from IPR Medical?

IPR Medical is an ISO 9001:2015 certified supplier of patient monitoring accessories, infusion pump parts, and medical equipment. Our team works with biomedical departments, materials managers, and clinical staff every day to find the right compatible cables and sensors quickly and at a fraction of OEM cost. Beyond accessories, IPR Medical buys, sells, and repairs patient monitoring equipment in-house, and stocks a deep inventory of replacement parts.

IPR Medical buys, sells, repairs, and stocks parts for Masimo SET pulse oximetry equipment. Contact us at 855-477-8866 or cs@iprmed.com.
