What Is the GE 394111-012 Compatible 5-Lead ApexPro FH Snap Leadwire?

The GE Healthcare 394111-012 compatible telemetry ECG leadwire is a reusable, aftermarket 5-lead set with snap electrode connectors that plugs directly into a GE ApexPro FH telemetry transmitter. The 5-lead configuration of four limb leads and one chest lead is the most common telemetry setup on cardiac and step-down floors. It provides multi-lead arrhythmia monitoring and a precordial view while the patient walks freely. It is a compatible replacement, not an original GE part, and it is built to the same fit, form, and function as the OEM 394111-012, 394111-512, and 394111-006 lead sets.

Compatible Equipment Models

This compatible snap-end set is confirmed for use with the GE ApexPro FH telemetry transmitter and the Mindray/Datascope DT-4500 telemetry transmitter, which accepts the same molded lead set connector. It is not for Multi-Link bedside trunk cables. Confirm the transmitter model before ordering.

Design and Construction

Each of the five shielded leads is 3 ft (0.9 m) long and ends in a snap that clicks onto a standard snap electrode. The snaps sit flat and low under a gown, so they are less likely to snag on bedding or clothing during ambulation. All five leads meet at a molded DIN-style ApexPro FH connector that seats firmly in the transmitter. The leads follow the AHA color code: white for right arm, black for left arm, red for left leg, green for right leg, and brown for the chest lead. The gray TPU jacket is about 0.10 in (2.6 mm) in diameter and stays light and flexible for patient comfort. The set is latex-free, non-sterile, rated for adult and pediatric patients, weighs about 0.3 lbs, and ships one per bag.

When to Replace Your ApexPro FH 5-Lead Snap Leadwire

On busy telemetry units, 5-lead snap sets are handled every shift, and the snap retention springs gradually loosen. Replace the set when snaps release from electrodes too easily, when leads show repeated artifact or “leads off” alarms with fresh electrodes, when the molded connector feels loose in the transmitter, or when you find cracked jacketing, exposed shielding, or faded color bands. Keeping a stock of spare sets lets staff swap a failing set immediately instead of troubleshooting at the bedside.

Cross Reference and Interchange Part Numbers

This compatible 5-lead ApexPro FH snap leadwire, IPR Medical SKU EL-TAF5-90S-A, cross-references to GE Healthcare part numbers 394111-012 and 394111-512 and to Marquette part number 394111-006. It also interchanges with Curbell LW-394111-006, Sage Services Group L02-05FH-29S, and Unimed AP5-90S. Materials managers and purchasing staff can use any of these numbers to confirm the match against existing inventory, work orders, or requisitions. For clip-style attachment, IPR Medical also stocks the compatible GE 394111-005 5-lead grabber set.

Why Source Telemetry Leadwires from IPR Medical?

IPR Medical is an ISO 9001:2015-certified independent service organization that buys, sells, repairs, and stocks parts for patient monitoring, telemetry, and infusion equipment. We carry the full line of ApexPro FH-compatible lead sets, 5- and 6-lead in both snap and grabber styles, so materials managers can standardize telemetry supplies from one source at lower cost than OEM. Our team can help confirm the right lead set for your transmitters and support your telemetry and monitoring equipment with in-house repair services.

IPR Medical buys, sells, repairs, and stocks parts for GE ApexPro telemetry systems and GE patient monitors. Contact us at 855-477-8866 or cs@iprmed.com.
