What Is the GE 412682-001 Compatible 3-Lead Grabber Leadwire?

The GE Healthcare 412682-001 compatible 3-lead ECG leadwire is a reusable, aftermarket grabber-end lead set for GE’s Multi-Link ECG system. Three limb leads (RA, LA, and LL) carry signals from the patient’s electrodes to a Multi-Link trunk cable, supporting basic heart rate and rhythm monitoring in pre-op, PACU, procedural sedation, transport, and general monitoring areas. It is a compatible replacement, not an original GE part, and it is built to the same fit, form, and function as the OEM 412682-001 lead set.

Compatible Equipment Models

With its GE Multi-Link connector, this compatible 3-lead grabber set fits GE CARESCAPE B105, B125, B450, B650, B850, and CARESCAPE ONE monitors, the Procare B40, Dash 1000 through Dash 5000 and Dash PRO monitors, Solar 3000, 8000, and 9500 systems, Tram and PDM modules, ApexPro CH telemetry, Eagle and Responder monitors, MAC-Lab, and Unity Systems. It also works with the Aisys CS2 anesthesia system, Logiq and Vivid ultrasound systems, the Corometrics 120, 250cx, and 259cx, Datex-Ohmeda Aestiva/5, E-PRESTN, M-PRESTN, and Unity equipment, and the Draeger Narkomed 6400. The trunk cable in service must accept a 3-lead set.

Design and Construction

The three shielded leads are each 3 ft (0.9 m) long and end in spring-loaded grabber/pinch clips. The clips attach to both tab and snap-style electrodes, which makes this set a practical choice for departments that stock more than one electrode type. A molded Multi-Link connector at the trunk end locks into the GE trunk cable. The leads follow the AHA color code: white for right arm, black for left arm, and red for left leg. The gray TPU jacket is about 0.10 in (2.6 mm) in diameter and resists tangling and repeated cleaning. The set is latex-free, non-sterile, rated for adult and pediatric patients, weighs about 0.3 lbs, and ships one per bag.

When to Replace Your GE Multi-Link 3-Lead Grabber Leadwire

Grabber clip springs weaken with constant opening and closing, especially in fast-turnover areas like PACU and pre-op. Replace the set when clips no longer grip electrodes firmly, when the ECG trace is noisy or drops out even with fresh electrodes, when the Multi-Link connector no longer clicks securely into the trunk cable, or when you see cracked jacketing near the clips, exposed shielding, or faded color bands. Keeping spare sets on hand prevents delays when a set fails at the start of a case.

Cross Reference and Interchange Part Numbers

This compatible 3-lead grabber leadwire, IPR Medical SKU EL-MQ3-90G-A, cross-references to GE Healthcare part number 412682-001. It also interchanges with AMC LW-3410029/3A, Curbell LDW-03BW-29AM-0000 and LDW-03BW-51AM-0000, and Elite Biomedical 91014 EBS. Materials managers and purchasing staff can use any of these numbers to confirm the match against existing inventory, work orders, or requisitions. For snap-style electrodes, IPR Medical also stocks the compatible GE 411203-001 3-lead snap set.

Why Source ECG Leadwires from IPR Medical?

IPR Medical is an ISO 9001:2015-certified independent service organization that buys, sells, repairs, and stocks parts for patient monitoring and infusion equipment. We carry GE Multi-Link-compatible lead sets in 3-, 5-, and 6-lead configurations with both snap and grabber ends, so every care area can stock the right set at lower cost than OEM. Our team can help match lead sets to your trunk cables and support your CARESCAPE, Dash, and Solar monitors with in-house repair services.

IPR Medical buys, sells, repairs, and stocks parts for GE CARESCAPE, Dash, and Solar patient monitors. Contact us at 855-477-8866 or cs@iprmed.com.
