What Is the Compatible Masimo 2054 Red DCI-dc12 SpO2 Sensor?

The Masimo 2054 (Red DCI-dc12) compatible SpO2 sensor (IPR SKU SS-009RB-AF30) is a reusable adult finger clip sensor that plugs directly into devices with a 20-pin Masimo Red SpO2 port. It is a compatible aftermarket replacement, not an OEM Masimo product, built to match the fit, form, and function of the original. The 9.8 ft (3.0 m) cable runs straight from the finger clip to the monitor, so no separate patient cable is needed. The longer cable gives the reach required when a Masimo Rad or Radical oximeter, Lifepak 15, or Zoll X Series sits on a shelf, pole, or cart away from the bedside. This sensor is intended for SpO2 monitoring and does not support rainbow co-oximetry parameters.

Compatible Monitor Models

This compatible sensor works with Masimo pulse oximeters and Pulse CO-Oximeters including the Radical-7, Radical (20-pin), Rad-5, Rad-5v, Rad-8, Rad-57, Rad-57c, Rad-57cm, Rad-57m, Rad-87, Rad-97, Rad-97 NIBP, Rad-97 with NomoLine Capnography, Pronto, Pronto-7, and Pronto with Next Generation SpHb. It is also compatible with Masimo-equipped configurations of the Physio-Control Lifepak 15 and Zoll X Series; Welch Allyn Connex Spot 75MT-B and related 73MT-B, 74ME-B, 74MX-B, and 75ME-B configurations; the Riester RVS 100; and the Comen K12 Pro. Confirm that your device has a 20-pin Masimo Red SpO2 input before ordering.

Design and Construction

The sensor uses a hard shell finger clip with a spring hinge that holds the emitter and detector in consistent alignment across the fingertip, making it well suited for spot checks and short-term continuous monitoring at the bedside. It is sized for adult patients weighing more than 66 lbs (30 kg). The 9.8 ft (3.0 m) cable terminates in a 20-pin Masimo Red connector that mates directly with the device. The sensor is reusable and supplied one per bag.

When to Replace Your 2054 Red DCI-dc12 SpO2 Sensor

Long direct-connect cables get stepped on, pinched in bed rails, and coiled repeatedly, so wear shows up along the cable as well as at the clip hinge, the finger pads, and the 20-pin connector. Replace the sensor when the clip no longer closes firmly, the finger pads are torn or hardened, the emitter or detector windows are scratched or discolored, the connector is cracked or has bent pins, or the cable shows cuts, kinks, or exposed shielding. Persistent “sensor off” alarms or readings that drop out when the cable is moved also point to a failing sensor. If a sensor fails to read on a monitor that passes self-test, try a known-good sensor to isolate the fault quickly.

Cross Reference and Interchange Part Numbers

This compatible sensor cross-references to Masimo 2054 (Red DCI-dc12) and Physio-Control 11996-000332. The aftermarket interchange number Praymed PSA0442-L also applies. The OEM 2054 has a 12 ft cable; this compatible version uses a 9.8 ft (3.0 m) cable with the same sensor and connector configuration.

Why Source Masimo-Compatible SpO2 Sensors from IPR Medical?

IPR Medical is an ISO 9001:2015-certified independent service organization that buys, sells, repairs, and stocks parts for infusion pumps and patient monitoring equipment. Compatible reusable SpO2 sensors give hospitals, EMS agencies, and materials managers a cost-effective way to keep Masimo-equipped oximeters, monitors, and defibrillators in service without paying OEM pricing. Our team can confirm fit against your device before you order, and we also offer in-house repair services, replacement parts, and refurbished equipment, so you can source accessories and service from a single partner.

IPR Medical buys, sells, repairs, and stocks parts for the Masimo 2054 Red DCI-dc12 SpO2 Sensor. Contact us at 855-477-8866 or cs@iprmed.com.
