What Is the GE 2104727-001 Compatible One-Piece EKG Cable?

The GE Healthcare 2104727-001 compatible one-piece EKG cable is a reusable, aftermarket diagnostic patient cable for GE Marquette resting electrocardiographs. The trunk and all 10 leadwires come as a single assembly, so there’s no separate trunk cable and lead set to pair up. The cable connects the patient’s electrodes directly to the cart for a standard diagnostic 12-lead ECG. It is a compatible replacement, not an original GE part, and it is built to the same fit, form, and function as the OEM 2104727-001 cable.

Compatible Equipment Models

This compatible one-piece cable is confirmed for use with GE Marquette MAC 400, MAC 500, MAC 600, MAC 800, MAC 1000, MAC 1100, MAC 1200, MAC 1600, MAC 2000, and MAC 3500 electrocardiographs, and with the Microsmart M. It is not for the MAC 5000 or MAC 5500, which acquire through the CAM 14 module, so confirm your cart model before ordering.

Design and Construction

The trunk runs 7.2 ft (2.2 m) from the electrocardiograph to the lead breakout. From there, 10 leads fan out in mixed lengths of 2.6 ft (0.8 m) and 3.9 ft (1.2 m), sized to reach the limb and precordial positions without excess slack. Each lead ends in a 4 mm banana tip that accepts banana-style electrode adapters, so staff can use the snap, tab, or clip adapter that matches their electrodes. The leads are AHA color-coded and labeled for RA, LA, LL, RL, and V1 through V6. The cable is defibrillation-proof, with built-in protective resistors that help protect the electrocardiograph if a connected patient is defibrillated. It ships one per bag.

When to Replace Your GE One-Piece EKG Cable

Because the leads are permanently attached, damage to a single lead means replacing the whole cable. Replace it when one or more leads show noise, baseline wander, or “lead fail” messages with fresh electrodes, when several leads drop out as the cable is moved, when banana tips no longer grip their adapters firmly, or when you find cracked jacketing at the breakout, faded lead labels, or a cart connector that no longer seats securely. A spare cable on the cart avoids canceled ECGs when a cable fails.

Cross Reference and Interchange Part Numbers

This compatible 10-lead one-piece EKG cable, IPR Medical SKU EKC10R-MQ-B-A, cross-references to GE Healthcare part numbers 2104727-001 and 2029893-001. It also interchanges with Sage Services Group A02-10B and Unimed E10R-MQ-B. Materials managers and purchasing staff can use any of these numbers to confirm the match against existing inventory, work orders, or requisitions. If you prefer a separate trunk cable and leadwires, IPR Medical also stocks the compatible GE 22341809 trunk cable and 2016032-001 banana leadwire set for the same MAC models.

Why Source EKG Cables from IPR Medical?

IPR Medical is an ISO 9001:2015-certified independent service organization that buys, sells, repairs, and stocks parts for diagnostic ECG, patient monitoring, and infusion equipment. We carry both one-piece cables and separate trunk-and-leadwire setups for GE MAC electrocardiographs, so cardiology departments and clinics can choose the setup that fits their workflow at lower cost than OEM. Our team can help match the right cable to your MAC fleet and support your ECG carts with in-house repair services.

IPR Medical buys, sells, repairs, and stocks parts for GE MAC resting ECG systems. Contact us at 855-477-8866 or cs@iprmed.com.
