Infusion Pump Repair

Hospira Plum A+ 3

$1,295.00 Original price was: $1,295.00.$995.00Current price is: $995.00.

The Plum A ®3 infusion system is designed to meet the growing demand for hospital wide device standardization, and serves a wide range of general floor and critical care needs. The infusion system consists of three component infusers, designated line 1, line 2, and line 3. By incorporating three lines into one unit, the Plum A 3 provides three primary lines, three secondary lines, and piggyback fluid delivery capabilities. Compatibility with the LifeCare® 5000 PlumSet® administration sets and accessories makes the Plum A 3 a convenient and cost-effective infusion system.

  • Flow Rate Range: 0.1 to 99.9 mL/hr (in 0.1 mL/hr increments); 100 to 999 mL/hr (in 1 mL/hr increments – Lines A and B)
  • Occlusion Pressure: 0.5 mL/hr minimum for each line
  • KVO: 1.0 mL/hr or the last primary delivery rate, whichever is less
  • VTBI Range: 0.1 to 99.9 mL (in 0.1 mL/hr increments); 100 to 9999 mL (in 1 mL/hr increments)
  • Accuracy: ± 5%
  • Power Requirement: 95-132 VAC; 47-62 Hz; 90 W (0.5 A, 250 VAC (6 V; internal; rechargeable) Less than 6 hours (if operating at 125 mL/hr on one line)
  • Bolus: 0.5 mL of air or larger; Cumulative – 0.5 mL of air out of 5.3 mL of fluid (Proximal 0.5 mL, total 1 mL (0.5 mL concurrent)

More Details
  • Dose calculation
  • Loading dose
  • Multi-step programming
  • Drug list
  • Nurse call back
  • Delayed start setting
  • Air trap
  • Air removal/backpriming
  • Air detection (proximal and distal)
  • Serial communication
  • Variable rate cap
  • Alarm history
  • Nurse call relay connector
  • Volumes infused (A, B, total volumes)
  • Variable distal pressure settings
  • Non-pulsatile volumetric accuracy
  • Microprocessor control
  • Large LCD
  • Panel back illumination on mains power
  • Lockout switch
  • Standard fulfill, partfill, syringe, and vial use
  • Enteral and parenteral fluid delivery
  • Blood and blood product delivery
  • Wide range of standard and specialty administration sets
  • Password protected keypad lock
Alarms
    • Distal Occlusion
    • Proximal Occlusion
    • Distal air-in-line
    • Proximal air-in-line
    • Low battery
    • Door open while pumping
    • Lockout violation
    • VTBI complete
    • Valve/cassette test failure
    • Nurse call
    • No act

Self-Discharge: 50% of charge is retained for a minimum of one month when the infuser is not connected to AC power or is not operating
