What Is the GE 2017003-001 Compatible 3/5-Lead ECG Trunk Cable?

The GE Healthcare Marquette 2017003-001 compatible ECG trunk cable is a reusable, aftermarket 3/5-lead patient cable that connects GE Multi-Link 3-lead or 5-lead leadwire sets to GE Marquette, CARESCAPE, and Datex-Ohmeda patient monitors. It supports impedance respiration monitoring and uses AHA color coding. It is a compatible replacement, not an original GE part, and it is built to OEM fit, form, and function.

Compatible Monitor Models

This compatible trunk cable is confirmed for use with GE CARESCAPE B450, B650, and B850 monitors and the GE B40, as well as Dinamap B105 and B125 monitors and ProCare B20 and B40 monitors. It also fits Marquette Dash 1000, 2000, 2500, 3000, 4000, and 5000 and Dash PRO 2000, 3000, and 4000 monitors, Eagle monitors and systems, Solar 3000, 8000, and 9500 systems, Tram 100 through 800 and Tram 451 modules, the PDM module, MAC-Lab, Responder 2000 and 3000 defibrillator/monitors, and Unity network systems. Other supported equipment includes the Aestiva/5 and Aisys CS2 anesthesia systems, GE Logiq 5 and 7 and Vivid 7, S5, S6, S70N, E80, E9, E90, E95, and i ultrasound systems with ECG input, Datex-Ohmeda E-PRESTN and M-PRESTN modules, and the Draeger Narkomed 6400.

Design and Construction

The 8.2 ft (2.5 m) trunk runs from the monitor to a Multi-Link yoke that accepts either a 3-lead or 5-lead leadwire set, so one trunk supports both configurations and a damaged leadwire set can be replaced without replacing the trunk. The cable supports monitoring use with impedance respiration and follows the AHA color standard. It is reusable after cleaning according to facility protocol and ships one per bag.

When to Replace Your GE 3/5-Lead ECG Trunk Cable

Replace the trunk cable when the monitor shows “leads off” or noisy, intermittent ECG on multiple leads with known-good leadwires and electrodes, when respiration readings drop out, when artifact appears as the cable is flexed, or when you find a cracked jacket, a loose yoke, or bent or corroded pins at either connector. Swapping in a known-good trunk and leadwire set quickly identifies which component is at fault.

Cross Reference and Interchange Part Numbers

This compatible 3/5-lead Multi-Link ECG trunk cable, IPR Medical SKU ET-5004-MQ-A, cross-references to GE Healthcare / Marquette part numbers 2017003-001, 2017003-002, 2106305-001, 2106305-002, 2106311-001, 2022948-001, 412931-001, 164L0025, E9002ZB, and 2269979. It also interchanges with AMC CB-515006, Curbell TCB-05ND-10AS-0000, CBT-05ND-10CM-0001, and 22104, Datrend MCET-5004MQA, Pacific Medical NEMQ1052, RPI KEC003 and KED021, Sage Services Group T02-05-36M, Schiller 55.065048, Tenacore MC006A and 535006, and Unimed MQ-2586. The OEM cables come in different lengths, about 12 ft for 2017003-001 and 2106305-001, 4 ft for the -002 versions, and 20 ft for 2106311-001, so confirm the 8.2 ft (2.5 m) length suits your setup. For 10-lead monitoring, IPR Medical also stocks the compatible GE 2017006-001 10-lead Multi-Link trunk cable, SKU ET-10004-MQ-A.

Why Source ECG Cables from IPR Medical?

IPR Medical is an ISO 9001:2015-certified independent service organization that buys, sells, repairs, and stocks parts for patient monitoring and infusion equipment. We carry compatible GE Multi-Link trunk cables, leadwire sets, and one-piece ECG cables alongside SpO2, NIBP, IBP, and temperature accessories, so biomedical teams can supply their GE fleet from one source at lower cost than OEM. Our team can help identify the right cable configuration for each monitor and support your GE equipment with in-house repair services.
