• Dimensions: 1.7″ W X 4.1″ H X 5.6″ L
• Weight: 1.25 lbs. (20 oz), including 9 volt battery and empty medication reservoir
• Resolution: Medication Cassette Reservoir or CADD^™ Administration Set, 0.050 ml per pump stroke nominal
• Power: 9 volt alkaline or lithium battery such as DURA-CELL^® Alkaline MN 1604 or ULTRALIFE® Lithium U9VL; CADD^™ External Power Source (EPS) Power Pack (reorder number 21-3801); AC Adapter.
• Battery Capacity: The expected life of a 9 volt battery is 12 hours at 100 ml/hour, or approximately 5 days at 10 ml/day (nominal). It is recommended that a new 9 volt battery be kept available for replacement if necessary.
• System Operating Temperature: 36°F to 104°F (2°C to 40°C)
• System Storage Temperature: -4°F to 140°F (-20°C to 60°C)
• Power Pack Charging Temperature: 50°F to 95°F (10°C to 35°C)
• Accuracy: ± 6% (nominal)
• Bolus Volume at Occlusion Alarm Pressure: 0.050 ml resolution administration Sets/Medication Cassette Reservoirs: <0.25 ml; 0.100 ml resolution administration sets: <2.0 ml
• High Pressure Alarm: 18 ± 9 psi
• Air Detector Alarm: Single bubble greater than 0.100 ml (can be turned ON or OFF)

PCA Delivery Mode :

• Reservoir Volume: 1 to 9999 or Not In Use; programmable in 1 ml increments, displayed in 0.1 ml increments (Default: 1 ml)
• Units: milliliters (ml), milligrams (mg), micrograms (mcg); (Default: milligrams)
• Concentration:
  • Mg/ml: 0.1, 0.2, 0.3, 0.4, 0.5, 1, 2, 3, 4, 5, 10, 15, …95, 100
  • Mcg/ml: 1, 2, 3, 4, 5, 10, 15, …95, 100, 200, 300, 400, 500
  • (Default = 1)
• Continuous Rate: 0-30 ml/hr (or the mg or mcg equilavent); Default: 0 mg/hr
• Demand Dose:
  • 0 to 9.9 ml (Default: 0 mg/hr)
  • Delivery rate (Continuous Rate Demand Dose): 125 ml/hr nominal
• Demand Dose Lockout: 5 minutes to 24 hours in the following increments:
  • 1 minute for values between 5 and 20 minutes
  • 5 minutes for values between 20 minutes and 24 hours
  • (Default: 5 minutes)
• Max Doses per Hour: 1 – 12 doses in 1 dose increments (will also be limited by the Demand Dose Lockout value); Default: 1
• Demand Doses Given: 0 to 999
• Demand Dose Attempts: 0 to 999
• Given: 0 to 99999.99 in 0.01 unit increments

• Clinician Bolus:
  • 0.1 ml to 20.00 ml (or mg or mcg equivalent)
  • Delivery rate (Continuous Rate Clinician Bolus): 125 ml/hr nominal

Continuous Delivery Specifications:

• Reservoir Volume: 1 to 9999 or Not In Use; programmable in 1 ml increments, displayed in 0.1 ml increments Default: 1 ml
• Continuous Rate: 0.1 – 350 ml/hr in the following increments:
  • 1 for values between 0.1 and 100
  • 1 for values between 100 and 350
  • Default: 0 ml/hr

*Use 9 volt battery for rates up to 250 ml/hr; use power pack or AC adapter for rates up to 350 ml/hr.

• Given: 0 to 99999.9 in 0.1 unit increments

TPN Delivery Mode Specifications:

• Reservoir Volume: 0 to 9990 or Not In Use; programmable in 1 ml increments, displayed in 0.1 ml increments (Default: 10 ml)
• Infusion Volume: 10 – 9990 ml in 10 ml increments (Default: 10 ml)

Download the operator’s Manual
